Includes
(1) EFD-K1612 Kick Drum
(1) EFD-S1250 Snare Drum
(1) EFD-T1070 Tom
(1) EFD-T1212 Floor Tom
(1) EFD-T1313 Floor Tom
(1) EFD-H14 Hi-hat
(2) EFD-C16 Crash Cymbal
(1) EFD-C18 Ride Cymbal
(1) EFD-C08 Splash Cymbal
(1) EFD-5X Module
(1) Tom Holder
(1) Splash Cymbal Arm
(1) Sound Module Arm
(3) Cymbal Stands
(1) Snare Stand
** Does not include Hi-Hat Stand, Throne, and Bass Drum Pedal.
Specifications
Kick EFD-K1612
Size: 16 x 12"
Zone: Head
Sensor: Multi
Head: Double-layered mesh with beater patch
Connector: Head (TRS Phones)
Features:Bass drum riser, Wood hoop
Snare EFD-S1250
Size: 12 x 5"
Zone: Head / Rim / Side-Rim
Sensor: Multi
Head: Double-layered mesh
Connector: Head/Rim, Side-Rim (2x TRS Phones)
Features: Birch shell, Colored hoop rubber, Side-Rim
Tom EFD-T1070
Size: 10 x 7"
Zone: Head / Rim
Sensor: Multi
Head: Double-layered mesh
Connector: Head/Rim (TRS Phones)
Features: Birch shell, Colored hoop rubber
Floor Tom 1 EFD-T1212
Size: 12 x 12"
Zone: Head / Rim
Sensor: Multi
Head: Double-layered mesh
Connector: Head/Rim (TRS Phones)
Features: Birch shell, Colored hoop rubber
Floor Tom 2 EFD-T1313
Size: 13 x 13"
Zone: Head / Rim
Sensor: Multi
Head: Double-layered mesh
Connector: Head/Rim (TRS Phones)
Features: Birch shell, Colored hoop rubber
Hi-Hat EFD-H14
Size: 14" (Top/Bottom)
Zone: Bow / Edge / Cup
Sensor: Multi (360° flat sensing + choke) / Optical
Connector: 6-pin
Features: Multi-optical sensor, Tru-motionâ„¢ hi-hat, Weight simulation, Fine engraved surface
General hi-hat stands compatible with φ12.7 mm (1/2") hole cymbal can be used.
EFNOTE 5X sound module does not support hi-hat cup zone.
Hi-Hat EFD-H14
Size: 14" (Top/Bottom)
Zone: Bow / Edge / Cup
Sensor: Multi (360° flat sensing + choke) / Optical
Connector: 6-pin
Features: Multi-optical sensor, Tru-motionâ„¢ hi-hat, Weight simulation, Fine engraved surface
General hi-hat stands compatible with φ12.7 mm (1/2") hole cymbal can be used.
EFNOTE 5X sound module does not support hi-hat cup zone.
Ride EFD-C18
Size: 18"
Zone: Bow / Edge / Cup
Sensor: Multi (360° flat sensing + choke)
Connector: Bow/Edge, Cup (2x TRS Phones)
Features: Weight simulation, Fine engraved surface
Splash EFD-C08
Size: 8"
Zone: Bow / Edge
Sensor: Multi (360° flat sensing + choke)
Connector: Bow/Edge (TRS Phones)
Features: Weight simulation, Fine engraved surface
Trigger Interface
3-Zone: Snare, Crash 1/2*, Ride
2-Zone: Tom 1/2/3/4, HH, Crash 3
1-Zone: Kick
Crash 1/2 support 3-zone with using Tom 4/Crash 3 cables.
In the EFNOTE 5X configuration, the Crash 2 cup is not supported when the Crash 3 is used.
Audio / MIDI Interface
Line (1/2) Output: 2x TS Phone (+4dBu, Unbalanced)
Phones (3/4) Output: Stereo Mini-Phone (320 mW + 320 mW @32Ω)
Audio Input: Stereo Mini-Phone (+2dBu Max)
USB Audio: 8-ch Output / 2-ch Input (Mac/Windows ASIO)
USB MIDI In/Out
Bluetooth Audio Input
Bluetooth MIDI In/Out
MIDI Out: 5-pin DIN
Audio / MIDI Interface
Line (1/2) Output: 2x TS Phone (+4dBu, Unbalanced)
Phones (3/4) Output: Stereo Mini-Phone (320 mW + 320 mW @32Ω)
Audio Input: Stereo Mini-Phone (+2dBu Max)
USB Audio: 8-ch Output / 2-ch Input (Mac/Windows ASIO)
USB MIDI In/Out
Bluetooth Audio Input
Bluetooth MIDI In/Out
MIDI Out: 5-pin DIN
Edit Parameters
Level, Pan, Tuning, Muffling (for each pad)
2-Band EQ (for each pad)
Ambience Effect (8 Types)
Pad Layer
Tom Holder
1x Tom holder arm
Geared L-rod tilter
Knurled carbon steel rod
L-rod diameter: φ11.5 mm (7/16")
Tube diameter: φ22.2 mm (7/8")
Height adjustment range: 700 -- 900 mm
Splash Cymbal Arm
1x Z-rod short
1x Z-rod long
Sound Module Arm
1x Sound module arm
1x Smartphone tray
Accessories
Brake-out cable: EFD-MULTI-AX
Brake-out cable: EFD-MULTI-B
4x Trigger cable 3.0 m: EFD-TRS-LL3
Cable ties
Quickstart guide
Snare drum stand and cymbal stand are optional.
Kick pedal, hi-hat stand and drum throne are sold separately.
